Organic fertilizer vertical pulverizer (also known as chain pulverizer) is a kind of non-screen, adjustable fine crushing equipment, which is optimized and designed based on the fine crushing equipment at home and abroad. It is one of the mainstream equipment widely used for crushing organic fertilizer materials. It can be used for final crushing of various materials such as mixed materials, gypsum, coal gangue, slag, copper ore, etc. It is also one of the crushing equipment commonly used in compound fertilizer industry, suitable for crushing raw materials and return materials, especially for materials with high moisture content. It has strong adaptability, is not easy to be blocked, and has smooth material discharge.
1. Simple and reasonable structure, low operating cost. Using the principle of stone hitting stone, the wear is small.
2. It has fine crushing and coarse grinding functions, high crushing rate and energy saving.
3. The inner wall is lined with polypropylene board, which alleviates the problem of sticking to the wall and difficult to clean.
4. The chain cutter head is made of special steel, which can effectively improve production efficiency. This machine has a reasonable structure, easy operation and strong applicability.
The organic fertilizer vertical crushing mechanism consists of a lower frame, a casing, upper and lower shaft seats, a main shaft, a hammer, a hammer bracket, a pulley, a motor frame and other parts. The power drives the main
shaft to rotate through a V-belt. The main shaft has two upper and lower bearing seats, which are installed at the upper and lower ends of the casing. The casing assembly is installed on the lower frame, and the main shaft is equipped with a hammer and a hammer bracket. The feeding hopper is installed on the upper part of the casing. In order to facilitate the loading and unloading of the hammer, a valve is opened on the casing to facilitate disassembly and maintenance.
