The pulverizer allows the moisture content of bio-fermented organic fertilizer materials to reach 25-50%, and the crushing particle size meets the granulation requirements (above 50 meshes). The crushing particle size can also be adjusted within a certain range according to user needs. It
The pulverizer allows the moisture content of bio-fermented organic fertilizer materials to reach 25-50%, and the crushing particle size meets the granulation requirements (above 50 meshes). The crushing particle size can also be adjusted within a certain range according to user needs. It is suitable for crushing lumps in the production of organic fertilizer and compound fertilizer, crushing various block fertilizers and other block materials of medium hardness. The machine uses high-strength, resistant carbide chain plates with synchronous speed during the crushing process. The inlet and outlet are reasonably designed, the crushed materials are uniform, not easy to stick to the wall, and easy to clean. Pig manure two-stage pulverizer Mushroom residue chicken manure crusher manufacturer Cow dung processing organic fertilizer crusher
1. The two-stage crusher adopts two-stage crushing. After the material is crushed by the cutting disc on the rotor disc, it is transported to the crushing chamber for secondary crushing by hammers and finally discharged from the discharge port.
2. The two-stage crusher is not designed with a screen bottom, so it will not be blocked by wet material crushing, causing the motor to burn out andaffecting production.
3 The two-stage crusher adopts a highly wear-resistant hammer head, and the hammer is made by forging, which is particularly strong and wear-resistant, stronger and more wear-resistant than ordinary hammers, which increases the service life of the hammer.
4. The two-stage crusher adopts two-way gap adjustment technology. If the hammer is worn, it does not need to be repaired. It can continue to be used by adjusting the position of the hammer. Pig manure two-stage crusher Mushroom residue chicken manure crusher manufacturer Cow dung processing organic fertilizer crusher
When the organic fertilizer double-stage crusher is working, driven by the motor, the two sets of rotors connected in series rotate at high speed at the same time. The materials in the machine cavity are crushed by the upper rotor
and then crushed again by the hammer of the rapidly rotating lower rotor. The materials in the inner cavity collide with each other at a high speed and crush each other, achieving the effect of hammering and crushing the materials,
forming coal slag particles with a discharge size of less than 3 mm.
Model | Capacity（t/h） | Maximum feeding force（mm） | Discharge particle size（mm） |
SCF600x400 | 10-15 | ≤110 | ≤3mm（2mm以下占85%以上） |
SCF600x600 | 20-25 | ≤110 | |
SCF800x600 | 40-50 | ≤120 | |
SCF800x700 | 45-60 | ≤120 | |
SCF800x800 | 50-60 | ≤180 | |
SCF900x800 | 50-70 | ≤180 | |
SCF1000x800 | 70-80 | ≤180 | |
SCF1100x1000 | 70-100 | ≤200 | |
SCF1400x1200 | 90-110 | ≤200 |
