Organic fertilizer disc granulator (disc granulator (also known as ball disc) is a volumetric metering feeding equipment, which can feed materials to the next process evenly and continuously, and can withstand large warehouse pressure. As a fine-grained material feeding equipment, it is
Organic fertilizer disc granulator (disc granulator (also known as ball disc) is a volumetric metering feeding equipment, which can feed materials to the next process evenly and continuously, and can withstand large warehouse pressure. As a fine-grained material feeding equipment, it is suitable for transporting various non-sticky materials in powder, material or small block states, such as coal powder, cement, clinker, limestone, shale, coal gangue, clay and other powder, granular or small block materials.
The disc granulator adopts an overall arc structure with a high granulation rate. The granulation disc is equipped with three discharge ports, which is convenient for intermittent production operations, greatly reducing labor intensity and improving The labor efficiency is high. The reducer and the motor are driven by a flexible belt. The start-up is smooth, the impact force is reduced, and the service life of the equipment is increased. The bottom of the granulating plate is reinforced with multiple radiating steel plates, which is sturdy and durable. The heavier, thicker and stronger base design does not require anchor bolts to fix it, and it runs smoothly. The main gear of the granulator is high-frequency quenched, and its service life is doubled. The granulating surface plate is lined with high-strength fiberglass for corrosion resistance and durability. This surface has the advantages of uniform granulation, high granulation rate, stable operation, sturdy and durable equipment, and long service life. It is an ideal equipment for the majority of users.
1. The granulating disc adopts an overall arc structure with a high granulation rate.
2. Long service life, new dredging design, with unpowered combined scrapers to clean the edges and bottom, and corner scrapers to clean the disc corners, combined with the unique processing technology of the disc body, good dredging and balling effects.
3. The bottom of the granulating disc is reinforced with multiple radiating steel plates, which is sturdy and durable. The heavy, thickened and sturdy base design does not require anchor bolts to fix it, and it runs smoothly.
4. The granulator disc is lined with high-strength fiberglass, which is corrosion-resistant and durable. It has the characteristics of high granulation rate, stable operation, sturdy and durable equipment, and long service life. It
is an ideal equipment for users.
The biofertilizer after being crushed is then mixed evenly by adding water before being fed into the disc granulator. As the disc rotates, the material gradually forms a spherical shape by rolling inside the disc. When it reaches a predetermined diameter, it is discharged from the disc and transported to the next process.
